It can be quite annoying to install software on a hpc without having sudo rights. I’ve had the experience installing packages for R can be especially be frustrating, as you’ll get error messages like:

* installing *source* package ‘V8’ ...
** package ‘V8’ successfully unpacked and MD5 sums checked
** using staged installation
Using PKG_CFLAGS=-I/usr/include/v8 -I/usr/include/v8-3.14
Using PKG_LIBS=-lv8 -lv8_libplatform
-----------------------------[ ANTICONF ]-------------------------------
Configuration failed to find the libv8 engine library. Try installing:
 * deb: libv8-dev or libnode-dev (Debian / Ubuntu)
 * rpm: v8-devel (Fedora, EPEL)
 * brew: v8 (OSX)
 * csw: libv8_dev (Solaris)
To use a custom libv8, set INCLUDE_DIR and LIB_DIR manually via:
R CMD INSTALL --configure-vars='INCLUDE_DIR=... LIB_DIR=...'
---------------------------[ ERROR MESSAGE ]----------------------------
<stdin>:1:16: fatal error: v8.h: No such file or directory
compilation terminated.
------------------------------------------------------------------------
ERROR: configuration failed for package ‘V8’
* removing ‘/home/pol.van-rijn/R/x86_64-redhat-linux-gnu-library/3.6/V8’

or

Error: package or namespace load failed for ‘reshape2’ in dyn.load(file, DLLpath = DLLpath, ...):
 unable to load shared object '/opt/conda/lib/R/library/stringi/libs/stringi.so':
  libicui18n.so.64: cannot open shared object file: No such file or directory

Those messages initially made me believe you need to install those packages system wide, however the trick here is to install them using Conda.

Here are the steps to do it:

1. Make sure anaconda is available: module load conda

2. Create a new environment: conda create --name r-3-6-3

3. Activate you environment conda activate r-3-6-3

4. Install R: conda install -c r r

   It is very important to install the packages using Conda and not in R, as you can get errors like these

   installing via 'install.libs.R' to /home/mpg08/pvanrij/.conda/envs/v8/lib/R/library/00LOCK-stringi/00new/stringi
   ** R
   ** inst
   ** byte-compile and prepare package for lazy loading
   ** help
   *** installing help indices
   ** building package indices
   ** testing if installed package can be loaded from temporary location
   Error: package or namespace load failed for ‘stringi’ in dyn.load(file, DLLpath = DLLpath, ...):
    unable to load shared object '/home/mpg08/pvanrij/.conda/envs/v8/lib/R/library/00LOCK-stringi/00new/stringi/libs/stringi.so':
     /home/mpg08/pvanrij/.conda/envs/v8/lib/R/library/00LOCK-stringi/00new/stringi/libs/stringi.so: undefined symbol: _ZTIN6icu_588ByteSinkE
   Error: loading failed
   Execution halted
   ERROR: loading failed
   * removing ‘/home/mpg08/pvanrij/.conda/envs/v8/lib/R/library/stringi’


5. Install v8: conda install -c conda-forge r-v8

6. Install brms: conda install -c conda-forge r-brms

7. Now start R and run a very simple model

   (r-3-6-3) bash-4.2$ R

   R version 3.6.3 (2020-02-29) -- "Holding the Windsock"
   Copyright (C) 2020 The R Foundation for Statistical Computing
   Platform: x86_64-conda_cos6-linux-gnu (64-bit)

   R is free software and comes with ABSOLUTELY NO WARRANTY.
   You are welcome to redistribute it under certain conditions.
   Type 'license()' or 'licence()' for distribution details.

     Natural language support but running in an English locale

   R is a collaborative project with many contributors.
   Type 'contributors()' for more information and
   'citation()' on how to cite R or R packages in publications.

   Type 'demo()' for some demos, 'help()' for on-line help, or
   'help.start()' for an HTML browser interface to help.
   Type 'q()' to quit R.

   > library(brms)
   Loading required package: Rcpp
   Loading 'brms' package (version 2.13.5). Useful instructions
   can be found by typing help('brms'). A more detailed introduction
   to the package is available through vignette('brms_overview').

   Attaching package: ‘brms’

   The following object is masked from ‘package:stats’:

       ar



   Do not only load the arms package, but also make sure it runs. You can test it using the example:

   fit1 <- brm(count ~ zAge + zBase * Trt + (1|patient),
               data = epilepsy, family = poisson())


8. And repeat the same steps on the compute node to double check if it works on there too.

It can happen you get errors, because Rcpp and rstan need to be compiled with the same compiler. If so, install Rcpp and rstan again using install.packages('Rcpp') and install.packages('rstan')

If you get errors about igraph, install it via Conda: conda install -c conda-forge igraph.

Click here to close

In this tutorial, we’ll cover how to setup remote debugging with the Pycharm IDE.

Motivation

First of all, why should you bother setting this up? When writing code, it can be practical to the code debug in an interactive fashion. This debugging can be hard if you run code remotely and need some special hardware like GPUs. Using interactive slurm sessions you can request such resources (e.g. srun –pty -p gpu -N 1 -n 4 /bin/bash requests access to a GPU and opens a bash, partition name depends on your hpc). You will be able to debug existing code by starting a python session and copy paste all lines of code. However, this approach comes with some downsides:

• you will need to copy paste every line,
• your code will not stop executing if an error occurs,
• you’ll have to take care of re-indenting intended code (see example below),

• line breaks in code that will cause errors,
• and many more annoying things…

A remote debugger will allow you to execute code until a certain point (aka breakpoint). From this moment on you’ll be able to interact with the code and inspect variables conveniently from your IDE.

Setting up the remote debugger

The first step is to open up PyCharm and go to Edit configurations…, see screenshot below

Now you need to add a new configuration, select Python remote debug

Now you need to fill in the following fields:

1. Give it a name, I called it HPC
2. Note the Pycharm version you are using, I have version 193.6494.30
3. Select localhost
4. Now pick a port, I use 8223 in this example. You need to make sure that this port is available
5. Finally click on (5) and make sure the mapping between your local files and remote files is correct

Now open a new terminal window (A) and

• connect to the HPC, e.g. ssh GWDG (or whatever alias or login you have to the hpc, e.g. ssh user@domain.com)
• load conda module load conda (you might need to load conda first)
• create a new environment if it does not already exist, conda create –name pycharm_demo
• activate the environment, e.g. source activate pycharm_demo
• install the right version of pydevd-pycharm (you noted down the Pycharm version in the last step). In my case, I run pip install pydevd-pycharm~=193.6494.30

Set a breakpoint

Go to a file you want to pause execution. On the top of the file insert

import pydevd_pycharm

In the line you want to stop, add the following line. Make sure you set the correct port here (I use the port 8223 here):

pydevd_pycharm.settrace('localhost', port=8223, stdoutToServer=True, stderrToServer=True)

Make sure the file is saved on the HPC server. In my case I made a file called test.py that contains the following contents:

import pydevd_pycharm
a = 1
pydevd_pycharm.settrace('localhost', port=8223, stdoutToServer=True, stderrToServer=True)
raise Exception()

Request required resources

The next step is to go back to terminal A and request for the required resources, e.g.:

srun --pty /bin/bash

The next step is to note the host name, you find this by running:

hostname

This will give you a host name, in this example it is gwdd173.

Setting up the ssh tunnel

Open a new terminal window (B) and type:

HOST=gwdd173 # add your host name
PORT=8223 # add your port
USER=pvanrij # change your username
ssh -J GWDG -R $PORT:localhost:$PORT $USER@$HOST

If the -J GWDG option does not work, you may have an older version of the ssh client. In that case you can try -o “ProxyCommand ssh GWDG -W %h:%p”.

Start the debugger

Go to Pycharm and click on the bug to start the debugger

Execute the program

Go back to terminal A and make sure you still have the right Conda environment activated (in my case pycharm_demo). Navigate to the folder that contains the file you want to pause and run:

python test.py

Now your code should stop and you can nicely debug your code
